BTH-8032 BTH 8132 Surgical 4K Medical Monitor Eco Friendly LED Backlight

BTH-8032 BTH 8132 Medical Monitor Environmentally friendly LED backlight

Product Description
The meidcal monitor adopt widescreen full HD panels with accurate color rendering, excellent layering, smooth and dynamic images and an expanded visual scope, which meet the current rapidly changing demands for medical displays and is able to provide clear and precise observation of surgical sites together with our camera system in minimally invasive surgery.This product is perfectly suited to meet the requirements of various kinds of endoscopic displays and ICU displays due to its white frame, water-proof design, antibacterial treatment, compliance with electromagnetic compatibility regulations and multiple video input/output interfaces.
Product Features
  1. High-performance I/P conversion
  2. Bright color separation deep compensation
  3. Environmentally friendly LED backlight
  4. Dynamic dark area color reconstruction technology
  5. Over Drive accelerates response and eliminates screen smear
  6. Digital image transient enhancement technology
  7. Unique white balance automatic adaptation technology
  8. Gamma value adjusted one by one before leaving the factory
  9. Personalized three primary color adjustment permissions
  10. Operate custom screen ratio adjustment between different modes

BTH-8032 BTH 8132 Surgical 4K Medical Monitor Eco Friendly LED Backlight
3840x2160 utra-high-definition image output showing richer textures and more accurate tissue identification.3840x2160 pixel image output, showing richer texture, more accurate tissue identification; Wider color gamut truly restore the color of organs and tissues, and locate blood vessels, lymph nodes and nerves faster.

Product NameBTH-8024BTH-8032
Screen Size24"32"
AppearanceWhite metal shell
Power SupplyExternal power supply
Power Supply Specifications12V/8.5A
Resolution1920x1080
Proportion16:9
Factory Brightness500±20%400
Highest Brightness600400
Contrast1000:11200:01:00
Display Color16.7M (6bit)16.7M 8bit
Dot Pitch0.2745x0.2745121.25(H)xRGBx363.75(V)
Response Time14ms8ms
Perspective178/178178/178
Dimensions (Without Base)570(W)x345(H)x65(D)mm746(W)x481(H)x67(D)mm
Installation StandardVESA 100x100mmVESA 200x100mm
Power Consumption80W max100W max
Energy SavingEPA, VESA
Operating Temperature5~40
MTBF (Mean Time Between Failures)>50,000 hours
Signal InterfaceHDMI/DVI/GA/CVBS/S-VIDEO
ApplicationEndoscope/electronic gastrointestinal endoscopy, laparoscopy
Factory CurveAMA2.6
Factory Color Temperature6500K
Color Gamut72% NTSC (sRGB)
Brightness Uniformity>75%
Brightness Equalization TechnologyBrightness stabilization system
Environmental Light CompensationN/C
Dot Clock Frequency154MHz400MHZ
Scanning Frequency50Hz-75Hz58HZ-97HZ
Backlight moduleLEDLED
